TSC TX610 – 4”, 600 dpi

Printer Specifications:

• Print Method: Thermal Transfer & Direct Thermal
• Resolution: 24 dots/mm (600 DPI)
• Max. Print Speed: 102 mm (4”)/second
• Max. Print Width: 106 mm (4.17“)
• Max. Print Length: 2,540 mm (100”)
• Processor: 32-bit RISC CPU
• Memory: 128 MB Flash memory /128MB SDRAM /
  microSD card reader for Flash memory
  expansion, up to 32 GB
• Sensors: Transmissive gap sensor /
  Black mark reflective sensor(position adjustable)
  /Ribbon encode sensor / Head open sensor
• Printer Language: TSPL-EZTM (Compatible to EPL, ZPL, ZPL II)

Media Specifications:

•  Media Type: Continuous, die-cut, black mark,
  fan-fold, notch (outside wound)
•  Media Width: 19 ~112 mm (0.75” ~ 4.4”)
•  Media Thickness: 0.055 ~ 0.254 mm (2.17 ~ 10 mil)
•  Media Core Diameter: 25.4 ~ 38.1 mm (1” ~ 1.5”)
