Zebra MC 3300

Physical Characteristics

Dimensions	MC3300 Straight Shooter (45° Scan and 0° Scan): 7.96 in. L x 2.94 in. W x 1.35 in. D 202.2 mm L x 74.7 mm W x 34.5 mm D MC3300 Turret/Rotating Head: 8.79 in. L x 2.94 in. W x 1.35 in. D 223.4 mm L x 74.7 mm W x 34.5 mm D MC3300 Gun/Pistol: 7.96 in. L x 2.94 in. W x 6.45 in. D 202.6 mm L x 74.7 mm W x 163.9 mm D
Weight	MC3300 Straight Shooter (0° Scan): 13.2 oz./375 g MC3300 Turret/Rotating Head: 13.3 oz./377 g MC3300 Gun/Pistol: 17.8 oz./505 g MC3300 (45° Scan): 13.5 oz./382 g
Display	4.0 inch capacitive; WVGA; color
Imager Window	Corning® Gorilla® Glass
Touch Panel	Corning® Gorilla® Glass touch panel with air gap
Backlight	LED backlight
Expansion Slot	User accessible MicroSD card slot; with 32GB SDHC and up to 256GB SDXC
Network Connections	USB 2.0 High Speed (host and client), WLAN and Bluetooth
Notification	Side LEDs and audible tone
Keypad	Numeric (29 Key), Function Numeric (38 Key), Alpha Numeric (47 Key)
Voice	PTT Express⁴ and Pro⁴ Support (internal speaker/microphone or wireless Bluetooth headset)
Audio	Speaker & Microphone
Audio Jack	All models except the Gun/Pistol: Integrated 2.5mm (Premium and Premium + models only—not available on Standard configurations)
Buttons	Two programmable side scan keys
